HOWO 4x2 5 Ton Light Duty Dump Truck

Name: HOWO 4x2 5 Ton Light Duty Dump Truck
Availability: InStock

This HOWO 4x2 light duty dump truck (mini tipper) is a compact, robust, and cost-effective solution designed for small-to-medium load transportation and unloading. Built on the reliable HOWO light truck chassis, it delivers powerful performance, excellent maneuverability, and long service life, making it the ideal choice for urban construction, municipal work, and agricultural operations in the Middle East, Central Asia, and other emerging markets.

Highlights:

✅ Maximum load capacity: 5 CBM (5000 Liters)

✅Chassis: Adopting a 4×2chassis manufactured by Sinotruk in China (left-hand drive / right-hand drive versions available)

✅ Self-dumping: hydraulic lifting

✅ Safety: Large-size brakes + ABS

Inquire Now

Howo 4x2 dump truck, suitable for engineering construction and mining

Your trusted choice for dump truck operations

Applications

This Sinotruk Howo 4x2 dump truck is mainly suitable for transportation in mines, quarries, construction sites, earthwork projects, sand and gravel yards, coal yards, rural roads, mountainous roads, as well as urban infrastructure construction and muck removal.

Engineering infrastructure: Earth and sand/gravel transportation
Emergency rescue: Debris flow and landslide clearance
Road and bridge construction: Asphalt and stone transportation
Municipal engineering: Urban pipeline network construction, demolition waste removal

Why choose our Sinotruk 4×2 dump truck？

Leading and flexible operating scope: it can easily handle sand and gravel, earthwork, ore, and muck, with higher transportation efficiency.
Stable and reliable quality：Howo is a globally recognized benchmark for engineering vehicles, featuring a sturdy frame and powerful performance, ensuring no breakdowns during continuous high-intensity operations in mines and construction sites.
Self-unloading function：It is equipped with high-brand hydraulic cylinders, ensuring stable and powerful lifting, fast unloading speed, reduced waiting time and increased turnover frequency.
Sturdy and Durable：High-strength steel plate cargo box plus reinforced frame, impact-resistant and wear-resistant, easily handling mines, muddy roads and rough pavements.

Comprehensive Safety Protection

Brake System Safety：Large-diameter brake drums + dual-circuit air braking, combined with the ABS anti-lock braking system, ensure greater stability when going downhill with heavy loads, deliver fast braking response, effectively prevent sideslip and tail flick, and make driving safer.
Safety Design of Hydraulic Lifting System：The lifting system is equipped with limit protection and explosion-proof valves to prevent the cargo box from being lifted too high and accidental falling due to pipeline rupture, making the unloading process more stable and safer..
Stable and safe driving：4×2dual rear axle drive delivers strong grip and stable center of gravity, preventing skidding on muddy, sloped or rough roads and ensuring smoother turning under heavy loads.

Technical Specifications

Category	Item	Unit	Data
Overall Dimensions	Length	mm	5995
	Width	mm	2200
	Height	mm	2450
	Rated Passengers	Persons	3
	Wheelbase	mm	3280
	Tires	/	7.50R16
Main Performance	Total Mass	T	7360
	Curb weight	T	3800
	Rated load capacity	T	3360
	Front axle	T	2600
	Rear axle	T	4760
	Loading capacity of the upper body	m³	4.25

Video

Drawing

Main Components

Howo classic front
Howo is globally recognized as the benchmark for engineering vehicles
Cab
Wide-body high-roof design with a sleeper berth for the driver's convenience
Front-end lifting oil cylinder

High lifting force and even stress distribution, enabling side unloading.
e.

Center-mounted double hydraulic lifting cylinders
The two oil cylinders operate synchronously, making the lifting process more stable and achieving efficient mechanized unloading.
Dual drive axle + Dual tire assembly structure
Withstand greater loads and adapt to various complex road conditions.
Shock absorber / suspension oil cylinder
Shock absorption and buffering, impact energy absorption,impact energy absorption.

Reliable Warranty & Global Support

12-Month Warranty: Full vehicle coverage (excluding wear parts) for your peace of mind.
Instant Technical Support: 24/7 technical feedback with immediate solutions for any fault.
Free Operator Training: On-site or remote training on hydraulics, safety, and operation.
Global Parts Supply: Rapid delivery of original hydraulic components to minimize downtime to the greatest extent
Multi-Brand Support: Professional diagnostic guidance even for your existing fleet of other brands.

Frequently Asked Questions

Q: What is the delivery lead time for a customized Sinotruk 4×2 dump truck?

A: Standard configurations are usually ready in 15–25 days. Custom painting or specific emission requirements may take up to 35 days.

Q: Does the truck come with a certification for international standards?

A: Yes, our aerial work platforms comply with ISO and CE standards, and the HOWO chassis meets global quality benchmarks.

Q: Can this truck operate in narrow city streets?

A: Absolutely. The HOWO 4x2 chassis is designed with a compact turning radius, making it highly maneuverable for urban maintenance.

Q: What are your shipping conditions?

A:Normally,we transport trucks via roll-on/roll-off ships, bulk carriers, and containers. Spare parts are packed in wooden cases and transported by container.

Q: Can you fully customize according to my requirements?

A: Yes. We have a professional R&D team and can accurately produce products according to your requirements.
